接触式清洁技术是一门高度专业化的学科。 用于描述其核心原理和组件的许多技术词汇在其他地方具有其他含义。 本技术词汇表提供了 Teknek 技术词汇表的定義,以在使用時帮助註釋主题并避免混淆。

Teknek 技术词汇表

英文名称 注释 中文
Adhesive A reverse wound adhesive roll that runs in contact with the elastomer roller retaining the contamination that has been removed by the cleaning roller. 粘尘纸
Adhesive Transfer The transfer of adhesive from Adhesive roll to Cleaning roller and then to the customer material. Such transfer can damage the process or product. 粘尘物残留
ANSI/ESD s20.20 2014 International standard for Development of an Electrostatic Discharge Control Program. Learn more at ANSI/ESD s20.20 2014
Anti-Static An antistatic material is a one which helps to reduce or eliminate build-up of static electricity 静电消除
Anti-Static Cleaner A term that is used by customer that do not understand how the system works. They think if you remove static then the product will be clean. 除静电设备
AOI Automatic Optical Inspection 自动光学检测机
AREF Adhesive Roll Eco Film AREF
AREP Adhesive Roll Eco Paper AREP
ARLS Adhesive Roll Low Static ARLS
CCR this is a PolymagTek term meaning Contact Cleaning roller 高分子聚合物接触式清洁胶辊
Chemical Transfer Sometimes referred to as 'Leaching' or 'Chemical Leaking'. In this context, it applies to chemicals or other substances that migrate from cleaning rollers or adhesive rolls. This is an important measurement process as the 'chemicals' migrate to the customer materials and can damage the process or product. 化学制剂残留
Coating / laminating Coating is the application of a liquid substance at variable thicknesses to a moving web. The methods of application can be varied. 涂敷/压合
Contact cleaning Where an elastomer roller touches the substrate that is being cleaned and transfers dry unattached particles to a reverse wound adhesive roll. 接触式清洁
Contamination control Process to ensure product and environment is kept free from contamination. 无尘管控
Converting The converting industry takes continuous rolls of thin, flat materials — known as webs — threads them through processing machines (such as printing presses, laminating, coating and slitting machines) and converts or changes the web of material into an intermediate form or final product. 柔性材料表面处理
DCR Dust Collecting Roller 黏尘胶辊
DCR pad Dust Cleaning Roller adhesive pad. Used to clean the DCR hand roller 手持式黏尘纸本
Elastomer roller The cleaning roller that touches the substrate 弹性清洁胶辊
FINAT Self Adhesive Federation with Regulated test standards. Learn more at FINAT协会
FPD Flat Panel Display. Devices to enable people to see content. Includes TV, Computers, Tablets, Smartphones etc. 平板显示器
FTIR Fourier transform infrared spectroscopy is a technique which is used to obtain an infrared spectrum of absorption or emission of a solid, liquid or gas. An FTIR spectrometer simultaneously collects high spectral resolution data over a wide spectral range. Used widely by Teknek. FTIR光谱
Hand roller DCR A hand-held roller that is used to clean substrates. The contamination is then transferred to an adhesive pad. 手持式黏尘胶辊
Industry 4.0 Automation and data exchange in manufacturing technologies - the internet of things. 工业4.0
Nanocleen™ Teknek elastomer roller. Removes Nano particles (tested using 25/45 nm silver particles) Nanocleen 纳米级黏尘胶辊
Nip Pressure The pressure as measured at the point that 2 rollers meet. Nip Pressure is typically measured in units of N/cm2 NIP压力
PCB Printed Circuit Board 印刷电路板
PCBA Printed Circuit Board Assembly 印刷电路板组装
PPU Particle Pick Up. An analytical test method developed by Teknek to measure the cleaning effectiveness of rollers and adhesives. The test uses three different types of particles to assess effectives. PPU is expressed in g/m2 精微颗粒清洁能力测试
Reel to Reel machine Machine that processes a continuous web 卷对卷清洁设备
Sheet cleaning Cleaning of individual sheets of materials. 片材清洁
Shore Hardness A measure of Hardness. Hardness may be defined as a material's resistance to permanent indentation. The durometer scale was defined by Albert Ferdinand Shore. 支撑硬度
SMT Surface Mount Technology 表面贴装技术
SPI Solder Paste Inspection 焊膏检测机
Surface Roughness Surface roughness often shortened to roughness, is a component of surface texture. 表面粗糙度
Taber Test Taber Abraser is a precision built instrument to perform accelerated wear testing of many materials including elastomers. The process to measure wear in items like cleaning rollers is defined in the ASTM D3489 standard Taber测试
Tack Tack is the property of adhesives that allows the immediate formation of a bond on contact with another surface - in other words it is a definition of the 'stickiness' of the adhesive 粘度测试
Web A web refers to a continuous sheet of relatively flexible material, like paper or film. 卷装材料
Web cleaning Cleaning a reel of material. The motion of the web drives the rollers and adhesives. 卷材清洁
Yield A measure of good units with no rework or scrap produced by an individual process. 产量
Yield improvement Improving the first time pass of usable product that is being manufactured. Results in a direct improvement to the product quality. 提高生产效率
Zero Defects Zero Defects is a management tool aimed at the reduction of defects through prevention. 零缺陷
